The IcoCar Shuttle 2+2 3.0 AC AGM is a 4-seater electric shuttle with foldable rear seat, 180Ah AGM battery, 5.0 kW AC motor, and premium features—ideal for hotels, resorts, and shuttle services.
The Shuttle 2+2 3.0 AC AGM by IcoCar is a robust electric shuttle vehicle designed for hospitality, camping, and transport services. It features four premium seats and a fold-down rear seat that converts into a cargo bed (110×80 cm) with an 80 kg load capacity. Powered by a 5.0 kW (6.8 HP) AC motor and six maintenance-free 8V AGM batteries (180Ah total), it offers a range of up to 60 km. The vehicle includes a 7″ LCD display, carbon dashboard, DOT laminated windshield with wiper, rain enclosure, and trailer hitch. Its rustproof aluminum frame and 10″ alloy wheels ensure durability and comfort.
| Shuttle 2+2 3.0 AC AGM – Technical Specifications | |
|---|---|
| Model | Shuttle 2+2 3.0 AC |
| Type | DG-M2+2 |
| Vehicle Class | Golfcar |
| Seats | 4 Premium Seats |
| Motor | 5.0 kW (6.8 HP) AC |
| Battery | AGM 6×8V, 180Ah |
| Range | Up to 60 km |
| Max Speed | 25 km/h |
| Charger | Delta-Q QuiQ 912-4800, 48V, 18A |
| Controller | Curtis 1236A, 48V, 450A |
| Drive | Electric 48V / AC |
| Transmission | Automatic |
| Brakes | Rear drum + parking brake |
| Suspension (Front/Rear) | McPherson / Trailer Arm |
| Steering | Self-adjusting rack & pinion |
| Dimensions (L×W×H) | 3100 × 1210 × 1960 mm |
| Wheelbase | 1680 mm |
| Track (Front/Rear) | 925 / 985 mm |
| Weight (Ready-to-drive) | 660 kg |
| Max Payload | 300 kg |
| Cargo Bed | 110 × 80 cm, 80 kg capacity |
| Wheels | 10″ Alloy rims, Kenda ProTour 205/50R10 |
| Frame | Aluminum, rustproof |
| Body & Canopy | High Glossy Polypropylene (PP) |
| Windshield | DOT laminated glass with wiper |
| Display | 7″ LCD Color Display |
| USB Ports | 2 |
| Lighting | DeLuxe roadlight kit (E-marked) |
| Storage | 2 lockable gloveboxes |
| Seatbelts | 3-point |
| Rain Enclosure | Included |
| Trailer Hitch | Included (7-pin plug) |
| License Plate | 2-line |
